Part number
RSA0K12K9A14
Master Type (K Fader) RS**K Series CP type
Basic information
- Number of resistor elements
- Dual-unit
- Direction of lever
- Vertical
- Travel
- 100mm
- Type
- CP type
- Lever type
- 9-T (T-Bar)
- Length of lever
- 8.2mm
- Total resistance
- 10kΩ
- Resistance taper
- 15A
Specifications
- Operating temperature range
- -10℃ to +60℃
- Durability
- Operating life
- 300,000 cycles
- Electrical performance
- Total resistance tolerance
- ±20%
- Maximum operating voltage
- 350V AC, 20V DC
- Rated power
- 0.25W
- Insulation resistance
- 100MΩ min. 250V DC
- Voltage proof
- 250V AC for 1 minute
- Mechanical performance
- Operating force
- 0.3±0.2N
- Stopper strength
- 100N
- Lever push-pull strength
- 100N
- Lever wobble (Both side)
- 1.312mm
- Lever deviation (One side)
- 0.5mm max.
- Minimum order unit(pcs.)
- Japan
- 50
- Export
- 100
Lever Dimensions
Circuit Diagram
Packing Specifications
Bulk
- Number of packages (pcs.)
-
- 1 case / Japan
- 50
- 1 case / export packing
- 100
- Export package measurements (mm)
- 524×374×201
