Part number
HSPPAD132A
MEMS Pressure Sensor HSPPAD (Water-proof Type) Series
Water-proof Type
MEMBERS ONLY
Basic information
- Size
- φ4、2.24mmt
- Function
- Atmospheric pressure detection (Water-proof)
- Pressure type
- Absolute pressure
- Features
- Water-proof pressure sensor with temperature-compensated digital output
- Interface
- I²C
- Output
- Pressure/temperature: 16-bit
Specifications
- Operating temperature range
- -10℃ to ＋60℃
- Pressure measurement range
- 300 to 1100hPa
- Supply voltage
- 1.7 to 3.6V
- Pressure accuracy
- ±2hPa
- Noise
- 2Pa (RMS)
- Current consumption
- 9.5μA (1Hz Sampling)
- Output type
- I²C
- Measured pressure type
- Absolute pressure
- Minimum order unit(pcs.)
- Japan
- 3,000
- Export
- 3,000
Packing Specifications
Tray
- Number of packages (pcs.)
-
- 1 case / Japan
- 6,000
- 1 case / export packing
- 6,000
- Export package measurements (mm)
- 210×210×230
Notes are common to this series/models
- This site catalog shows only outline specifications. When using the products, please obtain formal specifications for supply.
- Place your purchase order in N minimum package units (N: integer).
