Part number
AFDU1A031A
U Type AFDU Series
Automotive
MEMBERS ONLY
Basic information
- Type
- U Type
- Resonance frequency
- 175Hz
- Size
- 10.0×19.0×5.0mm
- Vibration Acceleration
- 4.9Gpp
- Drive voltage
- 5.5Vp-p (30 sine wave)
- Operating temperature
- -40℃ to ＋85℃
Specifications
- Resistance
- 6.5Ω±10% (@20℃)
- Minimum order unit(pcs.)
- Japan
- 600
- Export
- 600
Packing Specifications
Tray
- Number of packages (pcs.)
-
- 1 case / Japan
- 600
- 1 case / export packing
- 600
- Export package measurements (mm)
- 270×360×185
Notes are common to this series/models
- This site catalog shows only outline specifications. When using the products, please obtain formal specifications for supply.
- Please place purchase orders per minimum order unit (integer).
